入口光斑Input Beam Aperture (mm)

10

10

10

光柱位移Beam Displacement (mm)

12.54

12.54

12.54

跟隨誤差Tracking Error (ms)

0.18

0.14

0.16

重復精度Repeatability (μrad)

＜2

＜3

＜2

零位漂移Offset Drift (μrad/K)

＜15

＜15

＜15

增益漂移Gain Drift (ppm/K)

＜80

＜80

＜80

8小時以上漂移Long-term   drift over 8 hours (mrad)

＜0.3

＜0.4

＜0.15

1%全行程1% of full scale   (ms)

0.40

0.30

0.35

10%全行程10% of full   scale (ms)

1.20

1.00

1.10

定位速度Positioning Speed (m/s)

10.0

20.0

15.0

掃描角度Typical Scan Angle (°)

±12.5

±12.5

±12.5

增益誤差Gain Error (mrad)

<5

<5

<5

零位誤差Zero Offset (mrad)

<5

<5

<5

非線性度Nonlinearity (%)

<0.4

<0.4

<0.4

電源要求Power Requirements

±15VDC, ≥3A

±15VDC, ≥3A

±15VDC, ≥3A

數(shù)字接口Digital Interface

XY2-100

XY2-100

XY2-100

工作溫度Operation Temperature (℃)

25±10

25±10

25±10

重量Weight (kg)

1.9

1.9

1.9

入口光斑Input Beam Aperture (mm)

7

14

20

30

50

光柱位移Beam Displacement (mm)

9.77

16.42

25.25

35.61

62.25

跟隨誤差Tracking Error (ms)

0.15

0.23

0.45

0.70

1

重復精度Repeatability (μrad)

＜2

＜2

＜2

＜2

＜2

零位漂移Offset Drift (μrad/K)

＜20

＜15

＜15

＜15

＜15

增益漂移Gain Drift (ppm/K)

＜100

＜80

＜80

＜80

＜80

8小時以上漂移Long-term   drift over 8 hours (mrad)

＜0.4

＜0.3

＜0.3

＜0.3

＜0.3

1%全行程1% of full scale   (ms)

0.22

0.65

0.80

1.20

1.5

10%全行程10% of full   scale (ms)

0.8

1.60

2.50

4.50

 6.5

定位速度Positioning Speed (m/s)

25

10.0

5.0

3.0

 1

掃描角度Typical Scan Angle (°)

±12.5

±12.5

±12.5

±12.5

±12.5

增益誤差Gain Error (mrad)

<5

<5

<5

<5

<5

零位誤差Zero Offset (mrad)

<5

<5

<5

<5

<5

非線性度Nonlinearity (%)

<0.4

<0.4

<0.4

<0.4

<0.4

電源要求 Power Requirements

±15VDC, ≥3A

±15VDC, ≥3A

±15VDC, ≥3A

±15VDC, ≥3A

±15VDC, ≥3A

數(shù)字接口 Digital Interface

XY2-100

XY2-100

XY2-100

XY2-100

XY2-100

工作溫度Operation Temperature (℃)

25±10

25±10

25±10

25±10

25±10

重量Weight (kg)

1.6

2.3

5.0

5.2

 8.8

入口光斑Input Beam Aperture (mm)

10

14

20

30

光柱位移Beam Displacement (mm)

12.54

16.42

25.25

35.53

跟隨誤差Tracking Error (ms)

0.12

0.15

0.35

0.6

重復精度Repeatability (μrad)

＜2

＜2

＜2

＜2

零位漂移Offset Drift (μrad/K)

＜12

＜12

＜12

＜12

增益漂移Gain Drift (ppm/K)

＜50

＜50

＜50

＜50

8小時以上漂移Long-term   drift over 8 hours (mrad)

＜0.15

＜0.15

＜0.15

＜0.15

1%全行程1% of full scale   (ms)

0.30

0.35

0.70

1.10

10%全行程10% of full   scale (ms)

0.8

0.90

2.40

4.40

定位速度Positioning Speed (m/s)

18

14.0

6.0

4.0

掃描角度Typical Scan Angle (°)

±12.5

±12.5

±12.5

±12.5

增益誤差Gain Error (mrad)

<5

<5

<5

<5

零位誤差Zero Offset (mrad)

<5

<5

<5

<5

非線性度Nonlinearity (%)

<0.4

<0.4

<0.4

<0.4

電源要求 Power Requirements

±15VDC, ≥3A

±15VDC, ≥3A

±15VDC, ≥3A

±15VDC, ≥3A

數(shù)字接口 Digital Interface

XY2-100

XY2-100

XY2-100

XY2-100

工作溫度Operation Temperature (℃)

25±10

25±10

25±10

25±10

重量Weight (kg)

1.9

2.3

5.0

5.2
